AM COM-28

Specifications:

• • 3 Phase
  • Roller Bearing Crank
  • European B6000 Pump
  • Replaceable Shell Bearings
  • Molded Belt Guards to Maximize Cooling
  • Motor Size (HP): 7.5
  • Displacement (CFM): 28.4
  • Air Delivery (FAD): 23.9
  • Max Psi: 150
  • Tank Capacity (L): 200
  • Weight (Kg): 153

  Tips:

  Calculating CFM Requirements:
  Find the required air flow (CFM) of your specific air tool. This information will be in your tools user guide.

  • To find the minimum required CFM of the compressor you need multiply your tool’s required CFM by 1.5 Example: if you want to run a spray gun (4.5 CFM): 4.5 CFM x 1.5 = at least a 6.75 CFM compressor

  If you’re going to be running multiple tools you’ll need to add together the individual CFM of each tool.

  Calculating Tank Size:
  To find the minimum tank size of the compressor you need to multiple your tool’s required CFM by 6.

  • For example, if you run an impact wrench (6.75 SCFM): 6.75 CFM x 6 = at least a 40 litre compressor tank

  The above Tip is based on a general rule of thumb overview.
